Cim-Tek 40186 - Viking 1 Filter Housing ( 120 GPM)

Model Number: 40186 Product Information: Brand New Item Weight: 110 lbs ( 50 kg) Cim-Tek 40186 - Viking 1 Filter Housing has single 2" NPT filter housing with a replaceable element for filtration of gasoline, diesel fuel, fuel oils, and industrial fluids such as lubrication oils, hydraulic oils, syntheticoils, transformer oils, many solvents, and thinners may be filtered. The Viking 1 housing utilize the element measuring 6" in diameter by 18" in length. All Models are constructed of epoxy-coated carbon steel ( inside and out) and rated to 150 PSI working pressure with the flow rate of 120 GPM. Element sold separately. Please contact us for more information. Features: Max. Flow Rate: 120 GPM ( 450 LPM) Max. Working Pressure: 150 psi Standard 2" FPT Inlet / Outlet Flow Epoxy coated on inside and outside Inlet to Outlet dimensions 12" ( 2" NPT) ; 32-1/ 2” Tall 12" x12" bottom plate Carbon Steel housing 1/ 4" ports for the optional pressuregauge kit Requires 1 – 6" x18" element 3 Bolt Swing Down Lid Benefits: Removes common contaminants such as dirt, dust, and rust Increased filtering capacity Easy opening and access with swing down lid Full ASME Certification available Applications: Capable of filtering gasoline, ethanol blends up to E15, biodieselblends up to B100, diesel fuel, ultra-low sulfur diesel ( ULSD) , and fuel oils Industrial fluids such as lubrication oils, hydraulic oils, syntheticoils, transformer oils, many solvents, and thinners may be filtered Bulk fueling racks and bulk fluid transfer The Viking 1 is not to be used with aviation fuels Includes: Cim-Tek 40186 - Viking 1 Filter Housing ( 120 GPM) * * * Elements Not Included* * *
